Features & Consumer Benefit

Panasonic’s Standard Inverter offers both performance and better energy savings. Enjoy fast and powerful cooling sensations during start-up with a push of a button, and conveniently manage and control your air conditioning unit with the Panasonic Comfort Cloud app*.

Convenient Centralised Control

With the optional network adaptor CZ-TACG1 and Panasonic Comfort Cloud app, connect up to 20 air conditioning units at 1 location (up to 10 locations), remotely access all air conditioning features, track and monitor usage of air conditioner units using comprehensive energy statistics and identify issues with error notifications for effortless troubleshooting, all just from one mobile device.

Instant Cooling with A Push of A Button

POWERFUL Mode cools your room faster by 18%*, running both the compressor and indoor fan at super high speed for you to enjoy instant powerful cooling during start-up.

*Comparison of POWERFUL cool mode & normal cool mode by using 1.5HP Inverter Model.

Long Airflow with Big Flap

Big bottom flap directs cooling and comforting air across the room for an optimal cooling sensation.

Intelligently Balances Energy Savings and Comfort

ECO Mode with A.I Control learns and judges the optimal ECO level to maximise energy savings up to 20%* while providing consistent cooling comfort.

*Comparison of ECO Mode & normal mode by using 1.5HP Inverter Model.

Energy Saving with Inverter

Panasonic’s Inverter technology uses a Panasonic-made microcomputer and compressor to precisely control temperature, which provides a balanced comfort level in the environment while saving energy.

Eco-friendly R32 Refrigerant

Panasonic air conditioners have been increasingly adopting the eco-friendly R32 refrigerant. An excellent heat transfer medium for energy efficiency and cost savings. It also has low global warming potential, making it friendlier to the environment.

Fits Perfectly Anywhere

A compact size with minimalist finishing, the air conditioner fits easily in any interior. The timeless design blends harmoniously in tight and narrow spaces such as close to ceilings, near walls, above doors and windows to express a stylish and modern look, no matter where you install your air conditioning unit.

Basic Specification

• Model

  • Indoor (50 Hz)

    • CS-PU9XKH-1

  • Outdoor

    • CU-PU9XKH-1

• Cooling Capacity (min-max)

  • 2.78 (0.84-2.90) kW
    9,480 (2,860-9,890) Btu/h

• EER (min-max)

  • 11.85 (12.71-10.99) Btu/hW
    3.48 (3.73-3.22) W/W

• CSPF

  • 4.83 W/W

• Electrical Data

  • Voltage

    • 230 V

  • Current

    • 3.7 A

  • Power Input (min-max)

    • 800 (225-900) W

• Moisture Removal

  • 1.6 L/h
    3.4 Pt/h

• Air Circulation

  • Indoor

    • 10.3 m³/min (365 ft³/min)

  • Outdoor

    • 26.7 m³/min (940 ft³/min)

• Noise Level

  • Indoor (H / L / Q-Lo)

    • 38/26/21 dB (A)

  • Outdoor (H)

    • 47 dB (A)

• Dimensions (Indoor)

  • Height

    • 290 mm (11-7/16 inch)

  • Width

    • 779 mm (30-11/16 inch)

  • Depth

    • 209 mm (8-1/4 inch)

• Dimensions (Outdoor)

  • Height

    • 511 mm (20-1/8 inch)

  • Width

    • 650 mm (25-19/32 inch)

  • Depth

    • 230 mm (9-1/16 inch)

• Net Weight

  • Indoor

    • 8 kg (18 lb)

  • Outdoor

    • 17 kg (37 lb)

• Refrigerant Pipe Diameter

  • Liquid Side

    • ø 6.35 mm (1/4 inch)

  • Gas Side

    • ø 9.52 mm (3/8 inch)

• Pipe Extension

  • Chargeless Pipe Length

    • 7.5 m

  • Maximum Pipe Length

    • 20 m

  • Maximum Elevation Length

    • 15 m

  • Additional Refrigerant Gas*

    • 10 g/m

• Power Supply

  • Indoor

Comfort Features

• ECO Mode With A.I.

  • Yes

• Sleep Mode

  • Yes

• Inverter Control

  • Yes

• Powerful Mode

  • Yes

• Soft Dry Operation Mode

  • Yes

• Quiet Mode

  • Yes

• Airflow Direction Control (Up & Down)

  • Yes

• Manual Horizontal Airflow Direction Control

  • Yes

Cleaner Air Features

• Odour Removing Function

  • Yes

• Removable Washable Panel

  • Yes

Convenience Features

• 24-Hour Dual ON & OFF Real Setting Timer

  • Yes

• LCD Wireless Remote Control

  • Yes

• Wireless LAN Remote Control (For Internet Connection)

  • Yes (Optional)

• Wired Remote Control

  • Yes (Optional)

Reliability Features

• Random Auto Restart

  • Yes (32 Restart Patterns)

• Blue Fin Condenser

  • Yes

• Long Piping (max.)

  • 20 m

• Top Panel Maintenance Access

  • Yes

• Self-Diagnostic Function

  • Yes

Note

• Note

  • *When pipes are not extended from the chargeless pipe length, the required amount of refrigerant is already in the unit.
    Please read the Installation Instructions carefully before installing the unit, and the Operating Instructions before using it. Specifications are subject to change without prior notice.
